1.Applicable for pure off grid / backup power / self-consumption / on grid situation
2.PV input voltage range: 80Vdc-500Vdc
3.PV input current up to 40A
4.Supports battery mode & non battery mode
5.Battery & PV reverse polarity protection
6.pure sine wave output
7.Supports single-phase or three-phase parallel operation (up to 16 units)
8.Sleep mode triggered by low power output or low battery voltage
9.Independent BMS communication interface
10.Built-in WiFi for mobile monitoring *
11.Isolated RS485 interface:Connects with Bluetooth, WiFi, 4G, etc.
12.Optional 320 x 480 high-resolution color LCD screen or monochrome screen
13.Historical data recording function, storage capacity of 25000 records
14.Comprehensive electronic protection ensures safer and more stable operation
15.IP20 enclosure design with anti-dust kit
*Only applicable to color screen series
Specification
| Model | UCP5542-1050P20/C |
| Utility input |
| Utility Input Voltage | 176VAC to 264VAC (Default)
90VAC to 285VAC (Configurable) |
| Utility Input Frequency | 45Hz to 65Hz |
| Maximum Utility Charging Current | 100A |
| Switch Response Time | Switch Response Time – Inverter to Utility: 10ms
Switch Response Time – Utility to Inverter (when the load power is higher than 100W): 20ms |
| Inverter output |
| Inverter Rated Power (@30℃) | 5500W |
| 3-second Transient Surge Output Power | 8500W |
| Inverter Output Voltage | 220/230VAC±3% |
| Inverter Frequency | 50/60Hz±0.2% |
| Output Voltage Waveform | Pure sine wave |
| Load Power Factor | 0.2－1(VA ≤ Rated output power) |
| THDu (Total Harmonic Voltage Distortion) | ≤3% |
| Maximum Load Efficiency | 92% |
| Maximum Inverter Efficiency | 94% |
| Maximum Main Load | 5500W |
| Maximum Second Load | 5500W |
| Main Output Cut-Off Voltage | Equal to “Under Voltage Warning Voltage” |
| Second Output Cut-Off Voltage | Equal to “Low Voltage Disconnect Voltage” |
| Dual Output Recovery Voltage | Equal to “Low Voltage Reconnect Voltage” |
| Solar controller |
| PV Maximum Open-circuit Voltage | 500V (At minimum operating environment temperature)
440V (At 25℃) |
| MPPT Voltage Range | 85V to 450V |
| Number of MPPTs | 2 |
| PV Maximum Input Current | 20A+20A |
| PV Maximum Short-circuit Current | 22A+22A |
| PV Maximum Input Power | 2×3300W |
| PV Maximum Charging Current | 100A |
| MPPT Maximum efficiency | ≥99.5% |
| Battery |
| Battery Rated Voltage | 48VDC |
| Battery Work Voltage Range | 40.8VDC to 64.0VDC |
| Battery Maximum Charging Current | 100A |
| Others |
| No-load Losses | ≤1.1A |
| Test condition: Utility, PV and Load are disconnected, AC output is ON, fan stops, @48V input |
| Standby Current | ≤0.8A |
| Test condition: Utility, PV and Load are disconnected, AC output is OFF, fan stops, @48V input |
| Communication with BMS | RS485 |
| Communication with Portal | RS485 |
| Parallel Function | Yes, 12 units in standard, 16 units at most |
| Work Temperature Range | -20℃ to +50℃ (When the environment temperature exceeds 30℃, the actual output power is reduced appropriately) |
| Storage Temperature Range | -25℃ to +60℃ |
| Enclosure | IP20 (With ANTI-DUST KIT) |
| Relative Humidity | < 95% (N.C.) |
| Altitude | <4000M (If the altitude exceeds 2000 meters, the actual output power is reduced appropriately) |
| Certifications and Standards | IEC 62109-1, IEC 62109-2, IEC 61683, IEC 62368 |
| Mechanical parameters |
| Dimension (Length x Width x Height) | 590mm × 300mm × 163mm |
| Mounting size (Length x Width) | 568mm × 245mm |
| Mounting hole size | Φ9mm/Φ10mm |
| Net Weight | 15.5Kg |
